AltimeterOne

AltimeterOne

$59.95

AltimeterOne is a rechargeable digital altimeter with a clear, sunlight-readable LCD display. Its tiny size and rugged construction have helped to propel its use beyond model rockets and planes to kites, quadcopters, falconry, and other sports and activities.

In stock

SKU: JL-A1 Category:

Product Description

Features

  • Highly accurate 19-bit barometric pressure sensor can detect altitude changes of less than one foot
  • Sunlight-readable LCD display displays maximum flight altitude
  • New: History feature stores last 1000 flights
  • Advanced rechargeable Lithium Polymer battery
  • Recharges in less than 2 hours from any standard USB port (cable included)
  • Highly accurate pressure sampling 25 times/second
  • Power button turns device ON/OFF and RESETs the display between flights
  • Automatically powers down to conserve power
  • Handy tether point allows secure attachment, or independent streamer recovery
  • Rugged ABS construction to survive crashes
  • “Realtime Altitude Mode” displays current altitude above ground level in real-time
  • Replaceable parts include battery, LCD, and case

Here are some of the more interesting ways in which AltimeterOne has been used:

» Tethered to the leg of a hunting falcon
» As an on-screen altitude display in RC planes
» In science projects (click here for one example)
» In world-record attempts for high altitude kite-flying

The Jolly Logic AltimeterOne has been approved by the National Association of Rocketry for use in rocketry competitions.



Specifications

English Units
Metric Units
Size
0.57″ x 0.71″ x 1.93″
14.5mm x 18mm x 49mm
Weight
0.36 ounces
9.9 grams
Max Altitude
29,500 feet above sea level
9000 meters
Precision

Nearest foot
Nearest meter



How to Use AltimeterOne

Here’s a quick video demonstrating how to prepare AltimeterOne for each flight (“Launch”), as well as how to review previous flights (“History”).



AltimeterOne User Guide



AltimeterOne User Guide (Pre-2014 version)



Recent Release Log
Version 3.01
> Now with 1000 flight memory
> Eliminated “demo flight”
> Memory can now be completely cleared
> Battery gauge less jittery
> Odd behavior in 3.01 shows incorrectly low battery level if user holds button until display appears
> Fix: quick click to turn on will show correct level
Version 3.02
> Fixes odd behavior where battery is initially incorrectly displayed if user holds button until display appears
Version 3.03
> Bug fix for erasing last remaining flight and showing history with no flights

As Packaged

Weight 2.1 oz
Dimensions 8 × 5 × 0.5 in
